Girls Blazer Basic Pattern Calculator - 7-14 Years

Girls blazer pattern

The girls blazer pattern calculator can be used for 2 age groups 7-10 years old (122-140cm tall) and 11-13/14 years old (146-164cm tall).
The girls blazer block allows you to create any designs you want.
The jacket block is constructed to reflect the changing shape of girls from the age of seven.

Instructions for using the pattern calculator:
* Add your measurements in the yellow cells from the "MEASUREMENTS" tab. The basic measurements needed for the pattern should be made by using the sketch from the same sheet and the measurement code (ex. A, B, C, etc.)
* Press button "Calculate"
* In the "RESULTS/INSTRUCTIONS" tab, the dimensions for the blocks will be computed automatically.
By following the steps from "RESULTS/INSTRUCTIONS" and the drawing you will be easily able to make your own pattern. Good luck!

Measurements Code Value
[cm]
FILL IN
A
B
E
G
L
K
M
F

Garment measurements
Child measurements
Line Value
[cm]		 Instructions

Front and back sections
0 Square down and right from point 0.
0-N 1.5
N-1 50.0 Square right from point 1.
N-2 29.0 Square right from point 2.
N-B 18.1 Square right from point B.
N-A 9.1 Square right from point A.
N-S 3.9 Square right from point S.
2-3 14.4 Square right from point 3.
0-4 39.5 Square down from point 4 and mark points B1, W1 and 5.
0-N7 6.3 Draw the back neckline.
B-B3 14.5 Square up from point 8 and mark points 9 and 10.
6-7 2.0 Square right from point 11.
N7-S3 10.5
a 2.7
2-W 1.0 Square down from point W and mark points H and F. Connect points A and W.
B1-B5 14.0 Square up from point B5.
B5-A5 5.1
B5-B6 6.7 Square across from point B6 and mark points N2 and W6, H6.
Connect point N2 with point 6; extend the line past point N2.
N2-L 1.8
N2-8 10.0
8-S5 1.0 Connect points N2 and S5 with a slightly arched line.
B5-B2 5.5 Mark point B2 at the bottom of the armhole.
b 2.3
Draw the armhole line hrough points: S3, A3, a, B2, b, A5 and S5.
B2-B21 1.8 Square down from point B21 and mark points W2 and H2.
C 9.6 Draw a dart 1cm wide around point W2.
B3-9 2.9 Square right from point 9 and mark point A4 at the intersection with armhole line. Square down from point A4 and mark pont W7.
B3-10 2.0 Square down from point 10 and mark points W3, H3 and F7.
F7-F3 2.4 Draw the back side seam through points: A4, W3 and F3 (center back) and points: A4, W7 and F7 (gusset).
B1-O 3.5
W1-O1 1.5
O1-O2 6.0 Mark points O, O1 and O2 as the bottons positions.
O-L1 2.0 From point L1, draw a vertical line. Connect point L1 and point L.
5-14 1.5 Connect points 14 and F7.
15-F1 3.5 Draw the edge line of the blazer through points L1 and F1, as shown in drawing.
N2-11 4.1 Square right from point 11 and mark point N1.
11-12 1.5 Connect points 12 and N2 and extend the line past point N1 to the right.
N1-13 1.5 Draw the back neckline.

Pockets
B6-P1 2.4
P1-P2 7.5 . . 8.5 You can go with my measurements or substitute your own for the with of the pockets.
P2–P3 1.0
P2–P4 6 . . 8
W6–P5 5.2 Draw two parallel lines through points P5 and P6 to the hemline.
P5–P6 13.5 . . 14.5
P5–P7 12.5 . . 13.5

Sleeve
Two-Piece Sleeve Pattern here!
Girls blazer block
